LEDDL-HG-P2 Rd200-22W-DALI-930/940-WL

Electrical data

Nominal voltage	220|240 V
Voltage type	AC/DC
Power factor	0.9
Max. system power	22 W
Max. inrush current	5.25 A
Inrush time	47.24
Displacement factor (DF)	≥ 0.9
Max. number of luminaires per miniature circuit breaker B16 (MCB)	37
Max. number of luminaires per miniature circuit breaker C16 (MCB)	37
Max. number of luminaires per miniature circuit breaker C10 (MCB)	23
Max. number of luminaires per miniature circuit breaker C13 (MCB)	30
Frequency	50|60 Hz
Nominal voltage DC	180|280 V

Photometrical data

Colour temperature	3000|4000 K
Lumen	2860 lm
Equivalent to	CFL 2x26W
Colour consistency (SDCM)	4
Colour rendering index (CRI)	> 90
Luminaire efficacy	130 lm/W
CIE Flux Code	81 98 100 100 100

Light technical data

Beam angle	70°
UGR	19

Lifespan

Lifetime (L70)	100000 h
Lifetime (L80)	70000 h
On-/Off-cycles	100000

Capabilities

Dimmability	DALI2

Certificates and standards

Degree of protection (IP)	IP54
Protection class according to IEC 61140	II
Impact strength	IK02
Glow wire test	650°C
IP recessed part	IP20
Risk group (EN 62471)	RG0 / RG1 (22W & 30W & 40W)

Type of control gear	LED operating device current-controlled
With control gear	Yes
Driver failure rate (at 5,000 hrs)	1%
Input current	105 A

Reflector	High-gloss
Housing colour	White
Optical material	Polycarbonate
Finishing	White RAL9003

Width	226 mm
Length	226 mm
Height/depth	62 mm
Outer diameter	226 mm

Application temperature	25°C
Storage environment	-25|50°C
Operating temperature	-10|45°C
